UHM-TSR300S
3.5 Litre roll coater rated at 2.5 kg/hour. 300 mm coating width.
Actual unit photograph — 3.5 Litre tank
Roll Coaters
3.5 Litre roll coater
UHM-TSR300S is a 3.5 litre hot melt unit rated at 2.5 kg/hour, drawing 2,300 W from a 220 V AC, 11 A, 50 Hz, 1ø supply and running to a maximum of 220°C. 300 mm coating width.
- Tank capacity
- 3.5 Litre
- Melt rate
- 2.5 kg/hour
- Tank power
- 2,300 W
- Power supply
- 220 V AC, 11 A, 50 Hz, 1ø
- Max operating temperature
- 220°C
We size the unit against your grams per carton and cartons per minute, and quote the adhesive grade with it. Installation and operator training included.
What you get
- Roll coater, 300 mm coating width
- Manufactured at our own works in India
- Gun, hose and nozzle supplied as a matched set
- Tank size chosen from your actual consumption, not from a catalogue page
- Spares held for every model we build
- Available on short-term or long-term contract
Specified with it
- Applicator guns — manual or automatic, matched to the pattern
- Heated hoses — made to your line layout length
- Nozzles & modules — bead, dot, spiral spray or slot
- Spare parts — heaters, thermocouples, filters, seals
Technical specification
UHM-TSR300S data
| Tank capacity | 3.5 Litre |
|---|---|
| Melt rate | 2.5 kg/hour |
| Tank power | 2,300 W |
| Power supply | 220 V AC, 11 A, 50 Hz, 1ø |
| Max operating temperature | 220°C |
| Equipment line | Roll Coaters |
| Configuration | Roll coater, 300 mm coating width |
| Heating | Thermocouple controlled tank, hose and gun |
| Supplied with | Matched gun, heated hose and nozzle set |
| Spares | Held in stock for every model we build |
Typical values. Tank, hose set and nozzle are configured against your line, so the final specification is confirmed on the quotation.
Other models
Others in Roll Coaters
No other published model in this line yet.
Ask for a demonstration of the UHM-TSR300S
Send us the carton, the bead pattern and the line speed. We run the trial with the adhesive it will use.
